Customer: Oil Refinery

Services Provided: Fabrication of Structural & Misc. Steel

Pipe Rack and Pipe Modules - 2015

We had to fabricate all the steel to make a pipe bridge then load it on trucks to ship to the galvanizer and then to a fire proofer. Once all the members were fire proofed, the steel was brought back to us and assembled inside our fabrication shop in predetermined lengths.

The sections of the bridge were approximately 14’-8” square and ranged from 45’ long to 76’ long.
They were moved out of our shop on skates and loaded on trailers using a 55 ton crane and a 120 ton crane. The trailer would then take them to a location in our yard where they were then unloaded for pipefitters to install piping where it was required and for a fire proofing crew to fill in the block out sections that were required for assembly. After all processes were complete and went through QC they were loaded on trailers and shipped to the job site.

Customer: Cement Company
Location: Maryland

Services Provided: Project Management, Safety Management, General Contractor, Purchasing, Pipefitting, Welding, Civil, Pipe Design, Code Work, Demolition, New Construction, Maintenance, Repair, Mechanical and Millwright (Equipment Setting), Laser Alignment, Steel Erection, Excavation, Concrete, Fabrication (Steel, Pipe, & Vessel), Sprinkler-fitting, Project Costing & Budgeting, Value Engineering

Lee Mechanical was contracted as the General Contractors for this NSHAP Upgrade. This contract, which includes the installation and erection of a KHD designed PyroProcessing System, which will increase the line's production rate to 2400t/day and be compliant with the new NESHAP environmental regulations.

The project incorporates constructing a five-stage single-string Preheater tower over the existing kiln, while the kiln is in operation. Modify the existing six-pier rotary kiln to a two-pier kiln and add a new clinker cooler. The existing kiln will be cut to achieve a final length of 51m, transforming the existing long dry kiln system into a new, modern, energy efficient, fuel efficient, and environmentally friendly PyroProcessing system. The new system was equipped with a new whole tire handling system and will be capable of co-processing up to approximately 7% of whole tires as an alternative fuel.

Lee Mechanical was also over the erection of a new dry lime injection system. To reduce NOx emissions, as well as a modification of the existing SNCR system. New dust collectors were installed to meet stringent particulate emissions requirements.
We incorporated a new raw material grinding VRM system, coal dosing systems, as well as erection of structural steel.

Customer: Chemical Company in Missouri

Services Provided: Project Management, Safety Management, General Contractor, Purchasing, Pipefitting, Welding, Civil, Pipe Design, Code Work, Demolition, New Construction, Maintenance, Repair, Mechanical and Millwright (Equipment Setting), Laser Alignment, Steel Erection, Excavation, Concrete, Fabrication (Steel, Pipe, & Vessel), Sprinkler-fitting, Project Costing & Budgeting, Value Engineering

Plant Upgrade – 2015:
The debottlenecking in 2015 was a complete addition to a process plant and consisted of installation of structural steel building with metal siding and concrete floors, installation of several vessels and pumps, fabrication and installation of small and large bore piping, installation of HVAC and fireproofing systems, installation of all associated piping and tie-in connection to the existing system. This project was done in a hazardous area that required constant communication and coordination between Lee Mechanical, the customer, and all subcontractors. Lee Mechanical acted as General Contractor on this project. The project was done in a timely manner, within budget constraints, and without any accidents.

Install Package Boilers – 2015:
This project was the second and main phase for the installation of two package boilers and new boiler house building. Lee Mechanical installed all associated piping, stacks, fans, and did all code work related to the boilers. Lee Mechanical set, aligned, and assisted in startup of all the pumps and equipment. Lee Mechanical set pipe racks, structural steel platforms, walkways, and stairs. Lee Mechanical also stepped up and did the sprinkler work after the previous contractor was removed from site.

HVAC Install – 2015:
This project was to install the HVAC portion of the Warehouse addition. The scope included fabrication and install of duct work, procurement of materials, and managed subcontractors for controls and testing & balancing on the system.

Customer: Chemical Company
Location: Iowa

Services Provided: Project Management, General Contractor, Purchasing, Pipefitting, Welding, Demolition, New Construction, Mechanical and Millwright (Equipment Setting), Steel Erection, Excavation, Fabrication (Steel, Pipe), Plumbing, HVAC

Safety Project – 2014:
The a recently new site of this chemical company had a project to upgrade the ventilation and exhaust system to bring the site up to the company's standards. Lee Mechanical was contracted on this project and a few others that came after it on the site. This project consisted of:

• Fabrication and install of three large steel platforms.
• Install of two large air handling units and two large exhaust fans.
• Purchase and install of new unit heaters, gas piping, and ductwork.
• Demo several existing pieces of equipment & ductwork.
• Purchase and install of new drain pipes and plumbing.
• Purchase and install of new copper piping.
• Install multiple safety showers and eyewash stations.
• Insulate most of the piping.
• Install new SS exhaust piping in 3 areas.
• Purchase and install of several exhaust hoses with associated duct.
• Install of 5 laboratory hood stations with associated duct.
• Install of all new duct from new units and fans to existing duct.
• Install of smaller baghouse and associated duct.
• Purchase and install of controls.
• Testing and balancing for system.

Overall, the project did have some lag time on the owner supplied materials, but we worked with the schedule and made this project as smoothly as we could. The project was stretched out due to late delivery of owner supplied materials and the civil contractor that was removed from site (not contracted by Lee Mechanical), but overall Lee Mechanical installed in a timely and effective manner.

Customer: Injection Molding & Chrome Plating Company

Location: Missouri

Services Provided:
Project Management, Safety Management, General Contractor, Purchasing, Pipefitting, Welding, Civil, Demolition, New Construction, Maintenance, Repair, Mechanical and Millwright (Equipment Setting), Steel Erection, Concrete, Fabrication (Steel, Pipe), Project Costing & Budgeting

Platter Plumbing Replacement -2015:
The work on the platter plumbing and equipment replaced during normal operations of the plant required very close communications between the plant managers and Lee Mechanical supervision and electrical contractors in order to keep production running at normal capacity with tie-in work being performed over weekends. The work consisted of stainless steel and carbon steel pipe welding along with Kynor, CPVC and PVC piping. Replacement of pumps, specialty equipment, vessels and steel work was also a large portion of the work required to complete the project. The work was completed in a tight schedule and within budget.

Press Mold Renovation-2015:
The existing molding department equipment, mechanical services, and concrete was demolished out and replaced in a relocated area with all new updated equipment and plumbing services. The existing floor was removed and reinforced to withstand the new equipment weights and new overhead crane system. The plumbing for the new system was replaced with stainless steel, carbon and PVC piping with the plumbing for each machine ran underground and up through pipe risers. The project was within budget and completed in a timely manner.

Customer: Pigment Company
Location: Missouri

Services Provided:
Project Management, General Contractor, Purchasing, Pipefitting, Welding, Code Work, Demolition, New Construction, Repair, Mechanical and Millwright (Equipment Setting), Fabrication (Steel & Pipe), Project Costing & Budgeting

Amine Mechanical system -2015:
The work on the Amine system consisted of all new 2205 stainless steel weld pipe for the Amine system with all new carbon steel weld steam piping for cleaning out the Amine system. The old tank form tanks were reused with all new pumps and equipment. A new control room was added with new HVAC system to keep equipment temperatures at minimal levels and to off load trucks into tank form area. The project was completed within the scheduled timeline, within budget, and accident free.

Customer: Agricultral Company
Location: Indiana

Services Provided:
Project Management, General Contractor, Purchasing, Pipefitting, Welding, Demolition, New Construction, Mechanical and Millwright (Equipment Setting), Laser Alignment, Steel Erection, Excavation, Fabrication (Steel, Pipe)

Anhydrous Ammonia Heater Installation - 2015
The Anhydrous Ammonia heater installation consisted of the installation of a new Sigma Thermal Horizontal NG Fired Convection Heater, new underground stainless steel piping and electrical conduit to truck unloading stations, fabricate and install new eye wash stations at same, fabricate and install new low temperature ammonia piping
and new NG piping and controllers to the heater.

The Owner stipulated that all work could not interfere with ongoing truck loading at the three terminals and all work will be in and around hazardous areas (ammonia vapors) requiring constant communication and coordination between Lee Mechanical and the customer Lee Mechanical. The project was completed in a timely manner, within budget constraints, and without any accidents.

Customer: Agriculture Company
Location: Missouri

Services Provided: Project Management, Safety Management, General Contractor, Purchasing, Pipefitting, Welding, Civil, Pipe Design, Code Work, Demolition, New Construction, Maintenance, Repair, Mechanical and Millwright (Equipment Setting), Laser Alignment, Steel Erection, Excavation, Concrete, Fabrication (Steel, Pipe, & Vessel), Sprinkler-fitting, Project Costing & Budgeting, Value Engineering, Electrical wiring and controls, startup services.

Dust Collection and Plant Tower Upgrade – 2014:

The Project entailed the addition of a new plant wide dust collection unit and piping along with the addition of two new floors to the soy bean production plant. The work entailed removing and disposing of the existing roof and third floor and coming back installing a new third and a fourth floor with new structures and poured concrete floors. Upon completion of the floors/roof, new color sorting, vibrator conveyors, chutes, ducting, scales, bean sorters, where installed.

During the tower upgrade a new dust collection system was installed along with new foundations for the exterior unit and the duct support structures that where fabricated and installed. All new ducting was installed throughout the plant along with proportioning valves for dust collection control.
The third phase portion of the project was the erection of a new truck loading structure including the subbase dirt work, concrete foundation work, lighting, steel structure fabrication and installation, and scale installation.

Lee Mechanical was the general contractor subbing out to a civil contractor for foundations and pavement installations, electrical contractor to supply all the PLC controllers, wiring, conduit and cable tray runs, along with two new MCC rooms with associated hardware and electrical feeds.

The Owner stipulated that all work could not interfere with ongoing truck loading and unloading requiring constant communication and coordination between Lee Mechanical and the customer Monsanto. The project was completed in a timely manner, within budget constraints, and without any accidents.
